Hot Plates for Fancy Yarn Production
TSP hot plates provide controlled yarn heating for thick and thin yarns, melange yarns and other fancy yarn applications. They can also preheat heavy denier yarns when the machine’s existing heaters cannot achieve the required yarn temperature.
Controlled Heating for Yarn Effects
Hot plates support controlled irregular drawing of the supply yarn. Variation in drawing can produce differences in dye uptake, helping manufacturers create distinctive textures, colour variations and melange effects.
Ceramic guides at the yarn entry and exit support smooth handling, reduce friction and help maintain a consistent yarn path through the heating zone.
Key Features and Specifications
Plate Length
Available in lengths from 10 cm to 30 cm.
Yarn Capacity
Each hot plate processes two yarns simultaneously.
Yarn Tracks
Available with or without yarn tracks to suit the application.
Temperature Control
Microprocessor based temperature control.
Temperature Sensor
PT100 sensor for accurate temperature monitoring.
Temperature Range
0°C to 250°C.
Heating Uniformity
Uniform temperature distribution supports consistent processing.
Ceramic Yarn Guides
Integrated ceramic guides at both the entry and exit points.
Machine Compatibility
Designed for integration with a wide range of OEM textile machinery.
Applications
Fancy Yarn Production
Controlled heating for thick and thin yarns, melange yarns and variable dye uptake effects.
Heavy Denier Preheating
Additional yarn heating before the main heating stage where the existing heater capacity is insufficient for the required process.
Temperature Control
Heating conditions selected to suit the yarn and process requirements.
Machine Integration
Review mounting, controls and yarn path requirements for the existing machine.
Technical Support
Application guidance for installation, settings and performance evaluation.
